Pump2Status — Raspberry Pi monitoring of three rural water pumps
July 18, 2022
This document describes the hardware and software of a self-built water pump monitoring system installed on a 14-acre property in Addison County, Vermont. The system monitors three pumps (one shallow well, one drip irrigation booster, one pond submersible) using a Raspberry Pi 4 and a custom HAT board. It has been operational since June 2022 with two unplanned outages, both caused by power loss to the controller, not by software faults.
1. System overview
Each of the three pumps has three sensors attached:
- Current sense loop on the AC line (CT clamp, 30A range, 0-1V output)
- Pressure transducer downstream of the pump (4-20 mA loop, 0-100 psi)
- Flow meter on the output line (Hall effect, pulse output)
The Raspberry Pi polls all nine sensors every 30 seconds, applies range checks, logs to SQLite, and sends an SMS via Twilio if any reading goes outside the configured normal range for that sensor.
+--------------------+
Pump 1 -----> | Current Pressure | -----> Pi GPIO
| Flow |
+--------------------+
+--------------------+
Pump 2 -----> | Current Pressure | -----> Pi GPIO
| Flow |
+--------------------+
+--------------------+
Pump 3 -----> | Current Pressure | -----> Pi GPIO
| Flow |
+--------------------+
|
v
+-----------+
| Pi 4 |
| + HAT |
| + SQLite |
+-----------+
|
v
Twilio API
|
v
SMS to phone2. Bill of materials
| Component | Qty | Unit cost (USD) |
|---|---|---|
| Raspberry Pi 4 (4 GB) | 1 | 55 |
| Custom HAT PCB (designed in KiCad) | 1 | 18 |
| MCP3008 ADC (8-channel SPI) | 2 | 4 |
| CT clamp 30A 1V | 3 | 12 |
| Pressure transducer 0-100 psi 4-20mA | 3 | 28 |
| Hall effect flow meter G1/2 | 3 | 9 |
| 24V to 5V buck converter | 1 | 6 |
| IP65 enclosure | 1 | 22 |
| Misc. wiring, terminals, fuses | — | 30 |
3. Wiring notes
- Run all sensor wires in twisted pair, shielded if possible. The pump motors put significant noise on long wire runs.
- Tie the shield to ground at the controller end only. Never both ends.
- Use a separate fuse for each sensor power line. A shorted sensor should not take down the whole system.
- Mount the controller enclosure away from the pump motors themselves. At least 2 meters minimum.
- Run a separate ground wire back to the controller from each pump. Do not rely on the conduit or the pump frame for the ground reference.
4. Software (Python 3.9)
The polling loop is intentionally simple. It runs as a systemd service. There is no web framework; the dashboard is a single static HTML file regenerated from the SQLite database every minute by a separate script.
import time, sqlite3, smbus2
from datetime import datetime
from adc import read_mcp3008 # local helper
from alerts import send_sms
DB = '/var/lib/pump2status/data.sqlite'
INTERVAL = 30 # seconds
SENSORS = [
# (pump_id, name, channel, lo, hi, unit)
(1, 'current', 0, 0.5, 8.0, 'A'),
(1, 'pressure', 1, 20, 80, 'psi'),
(1, 'flow', 2, 0.5, 6.0, 'lpm'),
(2, 'current', 3, 0.3, 5.0, 'A'),
(2, 'pressure', 4, 15, 50, 'psi'),
(2, 'flow', 5, 0.3, 4.0, 'lpm'),
(3, 'current', 6, 0.4, 7.0, 'A'),
(3, 'pressure', 7, 10, 40, 'psi'),
(3, 'flow', 8, 0.5, 5.0, 'lpm'),
]
def poll_once():
conn = sqlite3.connect(DB)
ts = datetime.utcnow().isoformat()
for pump, name, ch, lo, hi, unit in SENSORS:
raw = read_mcp3008(ch)
value = scale(raw, name)
conn.execute(
'INSERT INTO readings VALUES (?,?,?,?,?)',
(ts, pump, name, value, unit)
)
if value < lo or value > hi:
send_sms(f'PUMP {pump} {name}={value:.2f}{unit} out of range')
conn.commit()
conn.close()
if __name__ == '__main__':
while True:
try:
poll_once()
except Exception as e:
send_sms(f'POLL ERROR: {e}')
time.sleep(INTERVAL)5. Configuration
Sensor thresholds are stored in a YAML file at /etc/pump2status/thresholds.yaml. They are reloaded automatically every 5 minutes without restarting the service.
# /etc/pump2status/thresholds.yaml
pumps:
1:
name: shallow_well_house
current: { lo: 0.5, hi: 8.0 }
pressure: { lo: 20, hi: 80 }
flow: { lo: 0.5, hi: 6.0 }
2:
name: drip_garden_booster
current: { lo: 0.3, hi: 5.0 }
pressure: { lo: 15, hi: 50 }
flow: { lo: 0.3, hi: 4.0 }
3:
name: lower_pond_submersible
current: { lo: 0.4, hi: 7.0 }
pressure: { lo: 10, hi: 40 }
flow: { lo: 0.5, hi: 5.0 }6. Lessons learned
- Version 1 of the controller caught fire because the buck converter was undersized. Use a 5V buck rated for at least 3A.
- Version 2 had ground loop issues that produced false readings on the current sensors. Star grounding (every sensor returns to a single ground point at the controller) fixed this.
- Version 3 logged data to a microSD card that wore out after four months. SQLite on tmpfs with hourly flush to a USB SSD is much better.
- Version 4 (current) has been stable since June 2022.
